The one chamber design allows the Mandrake Brake to be compatible with nearly all silencers regardless of the depth of the initial blast baffle. Due to the 1.375x24 adapter mounting thread becoming nearly universal in the suppressor market, means that these brakes allow mounting of suppressor models from nearly every modern manufacturer with no additional parts.
TECHNICAL SPECIFICATIONS
1/2 x 28 standard 3.28oz 1 7/16”
5/8 x 24 standard 2.91oz 1 7/16”
1/2 x 28 pinnable 4.29oz 2.25”
5/8 x 24 pinnable 4.61oz 2.25”
FNC Coating
Pinnable variant has wrench flats and pre drilled pin holes and steel pins
Non pinnable uses 13/16” socket for removal
